Photometrics Iris 9™ Scientific CMOS Camera
Photometrics Iris 9™ Scientific CMOS Camera
Schematics
Photometrics Iris 9™ Scientific CMOS Camera schematics
Specifications
- Sensor: GPixel GSense 5130 Scientific CMOS sensor
- Active array size: 2960 x 2960 (9 Megapixel)
- Pixel Area: 4.25µm x 4.25µm (18.06µm2)
- Sensor area: 12.61mm x 12.61mm | 17.8mm diagonal
- Peak QE%: >73%
- Read noise: 1.5e
- Full-well capacity: 13,000e
- Bit depth: 16-bit
- Readout mode: Rolling Shutter | Effective Global Shutter
- Binning: 2x2 (on FPGA)
- Cooling performance: Sensor Temperature | Dark Current
- Air cooled: 0ºC @ 30ºC Ambient | 0.5e-/pixel/second
Camera Interface
- Digital interface: PCIe
- Lens interface: C-Mount
- Mounting points: ¼ 20” mounting point on each side
Triggering Mode
- Input Trigger Modes: Trigger-First: Sequence triggered on first rising edge | Edge: Each frame triggered on rising edge
- Output Trigger Modes: Any Row: Expose signal is high while any row is acquiring data | All Rows: Effective Global Shutter – Expose signal is high when all rows are acquiring data | Signal is high for set Exposure time | Rolling Shutter: Effective Global Shutter – Expose signal is high when all rows are acquiring data | Signal is High for set Exposure time – Readout Time
- Output Trigger Signals: Expose Out, Read Out, Trigger Ready
